minaret (DFI ITOX CS101-Q370)

Summary

Minaret is the leftover parts from pixy's 11th gen upgrade.

Currently it is a motherboard, CPU, power brick, and a few accessories.

Notes

TODO

Hardware

Make DFI
Year 2019
Model ST102-CS-SVR
Chassis ST100
Power Supply EDAC EA11011D-1200 12V 8.33A
Processor Intel Core i5-8500T
Memory 4GB DDR4 2133 (Samsung M471A5143EB0-CPB)
Ports 4x USB A 3.1
  2x RJ-45 LAN
  HDMI 2.0
  2x DisplayPort 1.2
  4x DB-9 Serial
  2x Front USB A 2.0
  2x Front Audio Jacks
Graphics Intel UHD Graphics 630
Storage -
Display -
Int. Peripherals Intel I219-LM Gigabit Ethernet
  Intel I211 Gigabit Ethernet
  Mini-PCIe Renesas μPD720202 USB 3.0
Ext. Peripherals -
Dimensions
Length/Depth
Width
Height/Thickness
Weight

Software

Operating System
Unique applications

Log

[2026-09-04 Fri] Figuring what to do with this machine

I've been using this as a test bench, but I want to package it up and make something a bit easier to work with.

What I've already got to add to it:

  • Cooler Master Elite 110 case
  • Cooler Master Hyper 212 EVO tower heatsink

What I want:

  • more CPU: i7-8700 or i7-9700 (limited to 65W TDP by 100W supply)
  • 32GB DDR4-2666 sodimm kit
  • NVMe SSD
  • Mini-PCIe USB 3.0 controller (for front panel USB)

I'd actually like a Silverstone SG13 case, but the Elite 110 ticks most of the boxes, and is only a little bulky.

Elite 110 mods needed:

  • Replace PSU mount with a flat plate, 80mm fan mount, and maybe some vents
  • Check state of current fan, replace with 140mm?
  • Maybe leave the top HDD mount out for easier access

[2026-10-19 Mon] Case ideas didn't work out

I got hold of a different tower heatsink, but after lining it up on this board I realized it would block PCIe card installation. I decided to use it on another machine and move that into the CM Elite 110 case.

I did get a Mini-PCIe USB 3.0 controller; Part number MPCIE2U-R02 with Renesas UPD720202.

I also decided to use my M.2 to CFExpress adapter here with a CoceKov 256GB CFExpress Type B card for the NVMe SSD solution.

I'd still like to do a tower heatsink solution, but I'm also leaning towards a compact case with a single low-profile slot.

RAM upgrades seem unlikely, and 8th/9th gen CPU demand is still fairly robust so I'm holding off on that too.
