raider (Thinkpad X41)
Summary
Oldest personal laptop I still own.
Notes
- I think I use to have some wedge batteries for this, but they died. IBM calls them 'Extended Life Battery'.
- My current battery might be dead.
- This is the only IBM branded ThinkPad I own, but the Windows Coa says 'Lenovo Singapore'.
- BIOS reports 2.5GB. Spec sheet says 1.5GB max. Windows detects 2GB fine.
Hardware
| Make | IBM |
| Year | 2005 |
| Model | ThinkPad X41 |
| Chassis | ThinkPad X41 |
| Power Supply | 16V 4.5A |
| Processor | Intel Pentium M - 1.5 GHz |
| Memory | 2GB DDR2 5300 (Hynix HYMP125S64CP8-Y5) |
| Ports | 2x USB A 2.0 |
| VGA | |
| RJ-11 Modem | |
| RJ-45 LAN | |
| SD card slot | |
| 3.5mm Headphone | |
| 3.5mm Microhpone | |
| PC Card slot | |
| Infrared | |
| Graphics | Intel GMA 915GM |
| Storage | 16GB KingSpec 1.8" SSD |
| Display | 12.1" 1024x768 TFT LCD |
| Int. Peripherals | Intel PRO/Wireless 2200BG 802.11b/g |
| Broadcom NetXtreme Gigabit Ethernet | |
| Ricoh CardBus Controller | |
| CXT 56K Modem | |
| Ext. Peripherals | ThinkPad X4 UltraBase Dock |
| Dimensions | |
| Length/Depth | 23.2 cm |
| Width | 26.2 cm |
| Height/Thickness | 3.1 cm |
| Weight | 1.46 kg (3 lbs 3.4 oz) |
Software
| Operating System | Windows XP SP3 |
| Unique applications | KX-TAW848 Maintenance Console |
Links
Log
Ebayed
Bought as a used machine. I think this was my first 'real' laptop. Came with 60GB hard drive, and 1GB RAM. I think the dock was included since it mentions DVD.
SSD Upgrade
I got a cheap KingSpec 16GB SSD. It is PATA, and fits the weird 1.8" form factor.
I probably upgraded the RAM to 2GB around this time too.
The original drive is still in my drive collection.
I put XP back on it. Mostly just an upgrade to give it a little pep.
