engage (Advantech IPC-6606P3-25BE)
Summary
TODO
Notes
TODO
Hardware
| Make | Advantech |
| Year | 2015 |
| Model | IPC-6606P3-25BE |
| Chassis | IPC-6066 |
| Power Supply | Advantech / Sparkle FSP250-70PFU |
| Processor | Intel Core 2 Duo E8500 |
| Memory | 4GB DDR3-1333 Transcend TS512MLK64V3N |
| Ports | PS/2 combo |
| VGA | |
| RJ-45 LAN | |
| 2x DB-9 Serial | |
| Parallel | |
| 6x USB A 2.0 | |
| Graphics | Intel GMA X4500 |
| Storage | 1TB Seagate BarraCuda ST1000DM010 |
| Display | - |
| Int. Peripherals | Intel 82583V Gigabit Ethernet |
| Winbond W83782G Hardware Monitor | |
| ITE IT8888G PCI to ISA Bridge | |
| Ext. Peripherals | |
| Dimensions | |
| Length/Depth | 40 cm |
| Width | 17.4 cm |
| Height/Thickness | 25.4 cm |
| Weight | 8.44 kg (9 lbs 9.8 oz) |
Software
| Operating System | |
| Unique applications |
Log
Some PICMG
PICMG is cool. This one was cheap. I don't actually have a reason to own a Core 2 Duo system with PCI and ISA slots.
This one has some things I don't like:
- Advantech stuck a noisy 92mm fan on the intake of the IPC-6066 chassis.
- The PCA-6011 SBC has stiffeners along the edge connectors, but then it is unsupported next to the CPU heatsink so it has a good bend in it.
- It is pretty heavy due to the thick steel case.
Currently it boots Windows 7 Embedded, and it seems to be a Chinese localized version.
None of my DDR3 RAM sticks would POST in this thing so it is stuck on 4GB.
I put a Rocketfish RF-51SDCD 5.1 sound card in it.
Things I might do:
- Trade out all the fans (92mm intake, something CPU, 80mm PSU)
- PCI video card with HDMI out
- GPIB ISA card for playing with test equipment
- Maybe get some SDI video capture cards to play with. I looked at Aja Xena SD.
