delta (ThinkPad X280)

Summary

Primary laptop.

Notes

Dropped once off a high shelf. Display bezel popped apart, but was easily snapped back together.

Hardware

Make Lenovo
Year 2018
Model ThinkPad X280
Chassis ThinkPad X280
Processor Intel Core i7-8650U
Memory 16 GB DDR4 2400
Graphics Intel UHD Graphics 620
Storage Samsung 512GB NVMe SSD MZVLB512HAJQ
Display 12.5" 1920x1080
Ports USB C 3.1 gen 2 / Thunderbolt 3
  USB C 3.1 gen 1
  2x USB A 3.1 gen 1
  Ethernet Dongle Port
  HDMI 1.4
  3.5mm Headset
  Micro SD
Int. Peripherals Elan Touchscreen
  Chicony 720p Camera
  Synaptics Fingerprint Reader
  Intel Wi-Fi 6E AX210
  Intel Ethernet I219-LM
  Realtek Audio ALC257
Ext. Peripherals -
Dimensions
Length/Depth 21 cm
Width 30.8 cm
Height/Thickness 2.1 cm
Weight 1.28 kg (2 lbs 13 oz)

Software

Operating System Windows 10 Pro
  Debian Testing (bullseye)
Unique applications -

Log

[2018-10-19 Fri] A used Thinkpad

Bought on ebay. My first proper ultrabook. This was a nicely specced model, with a good period left on the warranty. I also picked up a nice 1TB portable SSD from the same seller.

[2019-02-05 Tue] Warranty fix, mis-assembled keyboard

Right control key rubber dome seemed upside down. Always clicked on key return. I brought it in to Micro Center to have it serviced under Lenovo's warranty, and they replaced the Keyboard.

[2019-04-14 Sun] After a broken Debian install

At some point I had issue with getting a non-bootable Debian install. For some reason my initramfs lacked the cryptsetup stuff. Here were my notes on fixing it.

  1. Boot Debian Live. Install some stuff, decrypt the disk:
sudo apt install cryptsetup lvm2
cryptsetup luksOpen /dev/nvme0n1p5 nvme0n1p5_crypt
vgscan
vgchange -ay
  1. Mount your partitions somewhere. chroot into the root directory. Edit cryptsetup initramfs hooks:
Listing 1: /etc/cryptsetup-initramfs/conf-hook
CRYPTSETUP=y
  1. Update initramfs (-d delete existing, may be necessary instead of -u)
update-initramfs -u
  1. Check your initramfs:
lsinitramfs /boot/initrd.img-5.x.x-1-amd64 |grep cryptsetup
  1. Note during this fix my dual boot windows system wasn't found. You'll have to run update-grub again once the system boots normally.
  2. Grub install might fail. My fstab was missing /boot for some reason. Needed to manually add the fstab line. Use the filesystem's UUID (dev/disk/by-uuid…).
  3. Unmount /boot/efi
  4. Save anything you want in /boot and delete those files (they would be shadowed by the filesystem mounted there otherwise and that might be confusing later).
  5. Mount /boot and /boot/efi
  6. Either reinstall the kernel packages or copy the files you saved from before back into /boot to ensure correct stuff.
  7. Update and install grub
update-grub
grub-install /dev/nvme0n1

[2023-08-30 Wed] Dealing with USB ethernet adapter power management

I ran into trouble with some Realtek 2.5GbE adapters that wouldn't work on Linux. The issue turned out to be bad power management or USB autosuspend setting. Not really about this machine (delta), but I wanted to make a note of it here since it is one of the few machines I will ever actually need 2.5Gbit speeds.

The solution I found was to disable autosuspend using tlp. I followed this advice on an askubuntu thread.

[2024-03-13 Wed] Wifi upgrade

I put in a Intel AX210 Wifi 6E card. Windows was a pain and made me get another network adapter to download the driver. Linux just worked. No BIOS whitelist to deal with.

I don't have Wifi 6 access points yet, but it works just as well as the 8265NGW it replaced.
