defenser (GuruPlug Server Plus)
Summary
TODO
Notes
- I modified the devce to replace the internal power supply with a 5.5x2.1mm jack.
- The plastic case is brittle and easily chips apart. Particularly the corners where the two halves join.
Hardware
| Make | Globalscale Technologies |
| Year | 2010 |
| Model | GuruPlug Server Plus |
| Chassis | GuruPlug |
| Power Supply | 5V DC |
| Processor | Marvell 88F6281 |
| Memory | 512 MB |
| Ports | 2x USB A 2.0 |
| 2x RJ-45 LAN | |
| JTAG header | |
| Serial header | |
| eSATA | |
| MicroSD | |
| Storage | 512 MB Flash |
| Int. Peripherals | Marvell Bluetooth |
| Marvell 802.11bg | |
| Ext. Peripherals | - |
| Dimensions | |
| Length/Depth | 9.5 cm |
| Width | 6.4 cm |
| Height/Thickness | 4.5 cm |
| Weight | 0.16 kg (5.6 oz) |
Software
| Operating System | |
| Unique applications |
Links
- [[][]]
Log
A GuruPlug with the JTAG/Serial adapter
Since I got a hold of a GuruPlug Server I had been looking for a the JTAG/Serial adapter. I settled on this Server Plus because it had two NICs, and the adapter.
It was modified to remove the power supply so it won't cook itself.
