blossom and cathedral (Acer CloudProfessor Stick PC)
Summary
Pair of little stick PCs I got as part of arduino/cloud/IoT learning kits. Originally came with Linpus Lite 2.2 OS.
blossom is running KDE, while cathedral runs Gnome.
Notes
- F2 enters BIOS
- They boot fine with no head attached.
Hardware
| Make | Acer |
| Year | 2017 |
| Model | CloudProfessor CPF G1U-500 |
| Chassis | Acer CloudProfessor Stick PC |
| Power Supply | 5V 3A micro USB |
| Processor | Intel Atom x5-z8300 |
| Memory | 2GB DDR3 |
| Ports | HDMI |
| USB A 3.0 | |
| MicroSD | |
| Graphics | Intel HD Gen8 |
| Storage | 16GB eMMC SSD |
| Int. Peripherals | Azurewave AW-AM691NF WiFi/Bluetooth |
| Ext. Peripherals | - |
| Dimensions | |
| Length/Depth | 10.8 cm |
| Width | 4.5 cm |
| Height/Thickness | 1.4 cm |
| Weight | 0.06 kg (2.1 oz) |
Software
| Operating System | |
| Unique applications |
Links
- [[][]]
Log
Debian on Stick PCs
Debian 11 (firmware iso, EFI boot) install seemed to go fine, but the system says "No Bootable Device".
Setting a supervisor password in the bios allows changing the secure boot setting to enabled. I was able to manually add the shimx64.efi to the BIOS EFI setup. Then removing the supervisor password leaves it in a booting state.
