aegis (ThinkPad X60)
Table of Contents
Summary
My most modern 32-bit machine.
Notes
- I have a cellular model, but I think the extra antenna was cut, and card removed before I got it.
- I remember it having hot palmrest issues. I can't remember exactly how I mitigated. I know I swapped the wifi card, and I may have removed the dial-up modem module at some point. It seems much cooler than I remembered.
Hardware
| Make | IBM/Lenovo |
| Year | 2006 |
| Model | ThinkPad X60 |
| Chassis | ThinkPad X60 |
| Processor | Intel Core Duo T2400 |
| Memory | 2GB DDR2 667 |
| Graphics | Intel Graphics Media Accelerator 950 |
| Storage | PQI 32GB SATA SSD |
| Display | 12.1" 1024x768 |
| Ports | 4-pin Firewire/IEEE-1394 |
| 3x USB A 2.0 | |
| 3.5mm Headphone | |
| 3.5mm Microphone | |
| RJ-11 Modem | |
| USB C Power Input (mod) | |
| CardBus slot | |
| RJ-45 LAN | |
| SD card slot | |
| VGA | |
| Int. Peripherals | Atheros AR5418 802.11abgn |
| Intel 82573L Gigabit Ethernet | |
| Broadcom BCM2045B Bluetooth | |
| STMicro Fingerprint reader | |
| Intel High Definition Audio | |
| Ricoh R5C552 IEEE 1394 | |
| Ext. Peripherals | ThinkPad X6 Ultrabase Dock |
| Dimensions | |
| Length/Depth | 24 cm |
| Width | 26.8 cm |
| Height/Thickness | 3.5 cm |
| Weight | 1.64 kg (3 lbs 9.8 oz) - with 75WH battery |
Software
| Operating System | OpenBSD 6.6 |
| Unique applications | - |
Log
Some used compact Thinkpad
Bought on ebay. $125 with 3GB memory, and 160GB hard drive.
USB C power jack
Replaced power jack with MikeP's USB C mod jack.
